PinTherm Infra Connect | Room thermostat

Digital room thermostat with Modbus and Ethernet

The Pintherm Infra Connect is a digital room thermostat to switch an INFRA on/off or control high/low or modulating based on room temperature. The settings of the thermostat can be read and/or modified with Modbus or Ethernet. The thermostat can be connected to the BMS (building management system).

Features

Power : 230Vac / 50Hz
Own consumption : < 9W
Clock : 24 hour clock with automatic summer/winter time switching
Switching programs : 3 switching programs a day
Switching differential : 1°C
Dimensions : 166 x 160 x 106mm (bxwxh)
Weight : 880 grams
Protection class: IP-54
Installation environment:
– Transport/storage : -20°C until +70°C
– Operational : -10°C until +60°C
– Relative air humidity : 0-90% not condensating
Switch contact(s)*:
– Heating : 230Vac/16A (4A)
– Others : 230Vac/10A (2,5A)
Temperature setting : 0 until 39°C per 1°C adjustable
Overtime timer : adjustable 1, 2 or 3 hours (060, 120, 180)
Calibration : adjustable from -3.5°C until +3.5°C
High/low switching : Temperature 1K, 2K, 3K or manual. Pintherm Infra Connect always starts 20 min on high a heat demand.
Languages : NL/EN/DE/FR/PL/RO/LT
Fuse : 6A

Article code

0629109

Accessoires

External black bulb sensor (order code: 0629087)
