Control cabinet W9 GS+

Steel box with cylinder lock
One 230V power supply group per devicewith a switchbox for several devices
Digital time switch with weekly programme
Day and night temperature regulator
Holiday switch to operate devices at the night-time temperature over longer periods

View this product

Control cabinet C10

Steel box with cylinder lock
Regulator for the room temperature and minimum inlet temperature restriction using 2-10Vdc control signal
Selector for heat/off/ventilate
Failure lamps for: – Burner failure – Intake air failure – Burner fan thermally off – Maximum failure – Dirty failure
Operating lamps for: – Burner on – Burner in operation – Release of control

View this product

Control cabinet C12

Steel box with cylinder lock
Regulator for the room temperature and minimum inlet temperature restriction using 2-10Vdc control signal
Selector for heat / off / ventilate
Digital time switch with weekly programme
Holiday switch to allow devices to operate at the night-time temperature over longer periods

View this product

Control cabinet C20

Steel box with cylinder lock
Regulator for the room temperature and minimum inlet temperature restriction using 2-10Vdc control signal
Selector for heat / off / ventilate
High/low selector supply fan selector
Failure lamps for: – Burner failure – Intake air failure – Burner fan thermally off – Maximum/gas pressure failure – Dirty filter

View this product

Control cabinet C22

Steel box with cylinder lock
Regulator for the room temperature and minimum inlet temperature restriction using 2-10Vdc control signal
Selector for heat / off / ventilate
High/low selector supply fan selector
Digital time switch with weekly programme

View this product

MDC 230V Motor Control Upto 3.0KW

Steel box.
Solenoid switch to control the fan.
Connecting terminals for external room thermostat.
Connecting terminals for external 3-position selector.

View this product

Motor control box MDC 400V

Steel box
Solenoid switch to control the fan
Connecting terminals for an external room thermostat
Connecting terminals for external 3-position selector

View this product

What is a control cabinet?

The switch cabinets from Mark Climate Technology are sheet steel cabinets with electronic components for controlling air heaters, black tube heaters, air handling units and more. In addition, our control cabinets are equipped with lamps to indicate malfunctions or the operating mode of a device.

Our control cabinets can be equipped with time switches, selector switches and potential-free contacts. Room sensors are also supplied separately.

Customized control cabinets for any desired project

Controlling an HVAC system can be carried out in many ways. Everyone has their own ideas and wishes about this. Mark Climate Technology therefore has many options for this, from standard to project-based. The control of unit can be custom-made, for example a switch box that controls several devices. A lot is also possible with regard to the applied controls. For example, based on a day and night room temperature monitoring or on the room and supply temperature.

Mark has its own electrical engineering and assembly department and can therefore offer a solution for every application. Our advisors are happy to inform you about this. Please contact them about the possibilities of our range of control equipment.

The right control box for your Mark unit

Would you like advice on a custom switch box for controlling your Mark units? Please contact our technical advisors. We are happy to give you advice without any obligation. Send an e-mail to info@markclimate.com or contact us by telephone on +31 (0)598 656 612.
